BRNKL Hard Wired Shore Power Sensor WIRED_ALL_TRANS
BRNKL Hard Wired Shore Power Sensor WIRED_ALL_TRANS
SKU:BRNWIRED_ALL_TRANS
A Shore Power Hardwire Sensor lets BRNKL connect directly to an AC panel to monitor shore power. A shore power sensor is essential for boats that rely on shore power to keep batteries charged and systems healthy.
Supports 87~264VAC and 50 ~ 60Hz. Suitable for both North American and European use.
Specifications
Specifications
The BRNKL Shore Power Hardwire Sensor (Model: WIRED_ACC_TRANS) allows for direct monitoring of a boat's AC shore power status by connecting to the AC electrical panel.
Installation Details
Installation Details
Location: Should be installed indoors in a dry area near the boat's main AC electrical panel.
Mounting: Can be secured using two #4 screws.
Connectivity: Connects directly to the BRNKL base unit (e.g., BRNKL 5G or BRNKL Blue) via its analog/digital input ports.
Configuration: Once wired, the input must be set to "Shore Power" in the BRNKL app or web interface to enable real-time monitoring and event logging.d
Pelagic Power Tip
Pelagic Power Tip
For users who do not want to hardwire into a panel, a Shore Power Plug-in Sensor is also available for roughly $29.00, which simply plugs into any standard wall outlet.
